| PartNumber | LQ6NC02 |
| Znamka | SHARP |
| Velikost | 5.7 |
| Aplikacija | |
| Resolucija | 240×240 |
| Sestava | LCM |
| Svetlost | 120 |
| CR | |
| Barve | Full color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Analog |
| znamka plošče | SHARP |
| panelni model | LQ6NC02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 240(RGB)×240 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 113.8×87.6 mm |
| oris | 149.4×117 mm |
| površino | |
| svetlost | 120 cd/m² (Typ.) |
| kontrastno razmerje | |
| barve zaslona | Full color |
| odzivni čas | 30/50 (Typ.)(Tr/Td) |
| vidni kot | 45/45/30/10 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 2 pcsCCFLWithout Driver |
| signalni vmesnik | Analog RGB + Composite Video (NTSC), 20 pins |
| vhodna napetost | 5.0V (Typ.) |
