| PartNumber | ZJ050NA-08C |
| Znamka | Innolux |
| Velikost | 5.0 |
| Aplikacija | VOIP |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 250 |
| CR | 500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | INNOLUX |
| panelni model | ZJ050NA-08C |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 101.76×76.32 mm |
| oris | 117.65×88.43×5.9 mm |
| površino | Antiglare |
| svetlost | 250 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 50 pins |
| vhodna napetost | 3.3/10.4/17.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikacija | VOIP |
