| PartNumber | DLC0500AIG-2 |
| Znamka | Other |
| Velikost | 5.0 |
| Aplikacija | VDP |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0500AIG-2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 101.568×76.176 mm |
| oris | 117.65×88.43×6 mm |
| površino | Antiglare |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193140% |
| odzivni čas | 10/10 (Typ.)(Tr/Td) |
| vidni kot | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S6PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.)(VCC) |
| aplikacija | VDP |
