| PartNumber | WF57STIACDNG0 |
| Znamka | Winstar |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | Grayscale |
| Osvetlitev ozadja | WLED |
| Vmesnik | 8/16-bit |
| znamka | Winstar |
| velikost diagonale | 5.7 inch |
| slikovnih pik | 320×240 [QVGA] 70PPI |
| aktivno območje | 115.2(H)×86.4(V) mm |
| območje okvirja | 117.9(H)×89.1(V) mm |
| svetilnost | 800 cd/m² (Typ.) |
| smer pogleda | 12 o'clock |
| vidni kot | - |
| podpira barvo | Grayscale |
| utež | - |
| hitrost sličic | - |
| tip vmesnika | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WF57STIACDNG0 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | Rectangle |
| obris dim. | 160(H)×109(V) ×9.24(D) mm |
| zdravljenje | Glare (Haze 0%) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| odzivni čas | - |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED , W/O Driver |
| namenjen za | Industrial |
| plošča na dotik | PCAP |
