| PartNumber | DLC0570BDG-T-2 |
| Znamka | Other |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 450 |
| CR | 300:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | DLC |
| panelni model | DLC0570BDG-T-2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 115.2×86.4 mm |
| oris | 127×100×8.75 mm |
| površino | |
| svetlost | 450 cd/m² (Typ.) |
| kontrastno razmerje | 300:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 15/35 (Typ.)(Tr/Td) |
| vidni kot | 70/70/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S7PWLEDEmbedded (LED Driver) |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
