| PartNumber | WEX025664AG |
| Znamka | Winstar |
| Velikost | 2.8 |
| Aplikacija | Automotive Electroni |
| Resolucija | 256×64 |
| Sestava | PM-OLED, OLED |
| Svetlost | |
| CR | |
| Barve | Mono(Green) |
| Osvetlitev ozadja | self |
| Vmesnik | CPU/SPI |
| znamka plošče | Winstar |
| panelni model | WEX025664AG |
| velikost plošče | 2.8" |
| vrsta plošče | PM-OLED, OLED |
| resolucija | 256×64, 94PPI |
| slikovnih pik | Rectangle |
| prikazno območje | 69.098(W)×17.258(H) mm |
| odprtina okvirja | 71.104(W)×19.26(H) mm |
| velikost obrisa | 84(W)×25.8(H) mm |
| površino | - |
| vidni kot | - |
| način prikaza | - |
| najboljši pogled na | Symmetry |
| odzivni čas | - |
| barve zaslona | Mono(Green) |
| tip svetilke | self |
| pogostost | - |
| zaslon na dotik | Without |
| voznik ic | TABBuilt-in SSD1322UR1 |
| teža plošče | - |
| aplikacija | Automotive Electronics Handheld & PDA Instruments & Meters |
| signalni vmesnik | CPU/SPI , 30 pins FPC |
| vhodna napetost | 3.0V (Typ.) |
