| PartNumber | V236BJ1-P01 Rev.CB |
| Znamka | Innolux |
| Velikost | 23.6 |
| Aplikacija | TV Sets |
| Resolucija | 1366×768 |
| Sestava | CELL , a-Si TFT-LC |
| Svetlost | |
| CR | 3000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | LVDS |
| proizvajalec | Innolux |
| ime modela | V236BJ1-P01 Rev.CB |
| velikost zaslona | 23.6 inch |
| vrsto zaslona | CELL , a-Si TFT-LCD |
| število slikovnih pik | 1366(RGB)×768 (WXGA) 66PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 521.471 × 293.184 (H×V) |
| obris (mm) | 535.06 × 307.34 × 1.32 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare (Haze 1%) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 3000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 8.5 (Typ.)(G to G) ms |
| dober pogled na | Symmetry |
| način dela | MVA, Normally Black, Transmissive |
| debelina stekla | 0.50+0.50 mm |
| transmisivnost | 5.6% (Typ.)(with Polarizer) |
| barvna globina | 16.7M 69% NTSC |
| osvetlitev ozadja | No B/L |
| masa | 510g (Typ.) |
| uporablja za | TV Sets |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| seznam gonilnikov ic | Built-in COF 2 source chips |
| vrsto signala | LVDS (1 ch, 8-bit) , 30 pins Connector |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
