| PartNumber | CLAA090NA06CW |
| Znamka | CPT |
| Velikost | 9.0 |
| Aplikacija | CNS |
| Resolucija | 1024×600 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 800:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | CPT |
| panelni model | CLAA090NA06CW |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.0 inch |
| resolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 196.608×114.15 mm |
| oris | 211.1×126.5×6 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S13PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 40 pins |
| vhodna napetost | 3.3/9.6/18.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikacija | CNS |
