| PartNumber | TV101WXM-NS0 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1280×800 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6 |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| velikost plošče | 10.1" |
| resolucija | 1280(RGB)×800, WXGA, 149PPI |
| prikazno območje | 216.96(W)×135.6(H) mm |
| velikost obrisa | 228.211(W)×148.86(H) ×4.59(D) mm |
| svetlost | - |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 50% NTSC |
| pogostost | 60Hz |
| teža plošče | 130g (Typ.) |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 45 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| panelni model | TV101WXM-NS0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Hard coating (2H), Antireflection |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| način prikaza | ADS, Normally Black, Transmissive |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| tip svetilke | 6 strings WLED , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Pad & Tablet |
