| PartNumber | TV101WUM-LL3 |
| Znamka | BOE |
| Velikost | 10.1 |
| Aplikacija | Pad & Tablet |
| Resolucija | 1200×1920 |
| Sestava | a-Si TFT-LCD, Assemb |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | BOE |
| model | TV101WUM-LL3 |
| velikost diagonale | 10.1 inch |
| vrsta | a-Si TFT-LCD, Assembly |
| slikovnih pik | 1200(RGB)×1920 [WUXGA] 225PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 135.36(H)×216.576(V) mm |
| obris dim. | 163.1(H)×237.14(V) mm |
| območje okvirja | - |
| zdravljenje | Hard coating |
| svetilnost | 320 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥10) |
| način delovanja | HADS, Normally Black, Transmissive |
| podpira barvo | 16.7M 71% NTSC |
| Izvor svetlobe | WLED [8S4P] , W/O Driver |
| utež | 225g (Typ.) |
| namenjen za | Pad & Tablet |
| hitrost sličic | 60Hz |
| plošča na dotik | In-Cell Touch |
| Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
