| PartNumber | TM101JDHG38 |
| Znamka | TIANMA |
| Velikost | 10.1 |
| Aplikacija | Industrial Medical I |
| Resolucija | 1280×800 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 6S5P |
| Vmesnik | LVDS |
| proizvajalec | TIANMA |
| ime modela | TM101JDHG38 |
| velikost zaslona | 10.1 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1280(RGB)×800 (WXGA) 149PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 216.96 × 135.6 (H×V) |
| obris (mm) | 231.22 × 150.6 × 6.6 (H×V×D) |
| površina okvirja (mm) | 219.96 × 138.6 (H×V) |
| zdravljenje | Hard coating |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | SFT, Normally Black, Transmissive |
| barvna globina | 262K/16.7M 50% NTSC |
| osvetlitev ozadja | 6S5P WLED , 30K hours , With LED Driver |
| masa | 276g |
| uporablja za | Industrial Medical Imaging VOIP Phone |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6/8-bit) , Connector 40 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
