| PartNumber | VVX10F004B00 |
| Znamka | Panasonic |
| Velikost | 10.1 |
| Aplikacija | PAD |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 600 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | Panasonic |
| panelni model | VVX10F004B00 1 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.1 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 217.44×135.9 mm |
| oris | 228.86×152.5×4.48 mm |
| površino | Hard coating, Antireflection |
| svetlost | 600 cd/m² (Min.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 10S6PWLEDEmbedded (LED Driver) |
| signalni vmesnik | MIPI (4 data lanes), 45 pins |
| vhodna napetost | 2.5/3.3V (Typ.)(IOVDD/VDD) |
| aplikacija | PAD |
