| PartNumber | TM101DDHG01-60 |
| Znamka | TIANMA |
| Velikost | 10.1 |
| Aplikacija | Industrial Automotiv |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | TIANMA |
| velikost plošče | 10.1" |
| resolucija | 1024(RGB)×600, WSVGA, 117PPI |
| prikazno območje | 222.72(W)×125.28(H) mm |
| velikost obrisa | 235(W)×143(H) ×5.4(D) mm |
| svetlost | 450 cd/m² (Typ.) |
| vidni kot | 80/80/75/80 (Typ.)(CR≥10) |
| najboljši pogled na | 12 o'clock |
| barve zaslona | 262K/16.7M 47% NTSC |
| pogostost | 60Hz |
| utež | 202g (Typ.) |
| panelni model | TM101DDHG01-60 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 225.52(W)×128.10(H) mm |
| površino | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 7/9 (Typ.)(Tr/Td) |
| tip svetilke | WLED , 30K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial Automotive Display |
| A101AIE40L0 | Aptus | 10.1 | 1280×720 |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| CLAA101WB03 | CPT | 10.1 | 1366×768 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| PJ101IA-01A | Innolux | 10.1 | 1280×800 |
| Q101IRE-LA1 | Innolux | 10.1 | 1280×800 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TV101WUM-NH0 | BOE | 10.1 | 1200×1920 |
| TV101WXM-NP0 | BOE | 10.1 | 1280×800 |
