| PartNumber | TM070RDH10-00 |
| Znamka | TIANMA |
| Velikost | 7.0 |
| Aplikacija | Industrial Digital P |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | TIANMA |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 800(RGB)×480 [WVGA] 134PPI |
| aktivno območje | 154.08(H)×85.92(V) mm |
| območje okvirja | 157.08(H)×89.39(V) mm |
| svetilnost | 450 cd/m² (Typ.) |
| smer pogleda | 12 o'clock |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.7M 50% NTSC |
| utež | TBD |
| hitrost sličic | 60Hz |
| model | TM070RDH10-00 1 Compatible |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 164.9(H)×100(V) ×6(D) mm |
| zdravljenje | Antiglare |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED [3S8P] , 20K hours , W/O Driver |
| namenjen za | Industrial Digital Photo Frame Portable DVD Player |
| plošča na dotik | Without |
