| PartNumber | TX18D41VM0EAA |
| Znamka | KOE |
| Velikost | 7.0 |
| Aplikacija | IA |
| Resolucija | 1024×600 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | HITACHI |
| panelni model | TX18D41VM0EAA |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 153.6×90 mm |
| oris | 162.8×103.1×4.5 mm |
| površino | |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S3PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit) + SPI, 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
