| PartNumber | TM028HDZ58 |
| Znamka | TIANMA |
| Velikost | 2.8 |
| Aplikacija | Mobile Phone |
| Resolucija | 240×320 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | 1S4P |
| Vmesnik | Parallel |
| proizvajalec | TIANMA |
| ime modela | TM028HDZ58 |
| velikost zaslona | 2.8 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 240(RGB)×320 (QVGA) 141PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 43.2 × 57.6 (H×V) |
| obris (mm) | - |
| svetilnost | - |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| vidni kot | 60/60/60/50 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 65K/262K 55% NTSC |
| osvetlitev ozadja | 1S4P WLED , No Driver |
| masa | - |
| uporablja za | Mobile Phone |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | Parallel RGB (1 ch, 6-bit) + SPI |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| 28QVF1H | SII | 2.8 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LS028B8PX05 | SHARP | 2.8 | 240×400 |
| LTE283QV-F01 | Samsung | 2.8 | 320×240 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
| TM028HDH21 | Tianma | 2.8 | 240×320 |
| TM028LDH01 | Tianma | 2.8 | 240×400 |
| TM028LDZ09 | Tianma | 2.8 | 240×400 |
