| PartNumber | TCG121XGLPAPNN-AN20-S |
| Znamka | Kyocera |
| Velikost | 12.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 750:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | Kyocera |
| model | TCG121XGLPAPNN-AN20-S |
| velikost diagonale | 12.1 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×768 [XGA] 105PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 245.76(H)×184.32(V) mm |
| obris dim. | 260.5(H)×203.4(V) ×10.8(D) mm |
| območje okvirja | 249.0(H)×187.5(V) mm |
| zdravljenje | Antiglare |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 750:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 18/12 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | AWV, Normally Black, Transmissive |
| podpira barvo | 262K/16.2M 50% NTSC |
| Izvor svetlobe | WLED , 50K hours , With LED Driver |
| utež | 670g |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
