| PartNumber | LMG9980ZWCC-01 |
| Znamka | KOE |
| Velikost | 12.1 |
| Aplikacija | IA |
| Resolucija | 800×600 |
| Sestava | LCM |
| Svetlost | 70 |
| CR | 30:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | HITACHI |
| panelni model | LMG9980ZWCC-01 |
| vrsta plošče | CSTN-LCD , LCM |
| velikost plošče | 12.1 inch |
| resolucija | 800(RGB)×600 , SVGA |
| način prikaza | STN, Normally Black |
| aktivno območje | 246×184.5 mm |
| oris | 275×202.5 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 70 cd/m² (Typ.) |
| kontrastno razmerje | 30 : 1 (Typ.) |
| barve zaslona | Color |
| odzivni čas | 170/130 (Typ.)(Tr/Td) |
| vidni kot | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| pogostost | 120Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (8-bit), 41 pins |
| vhodna napetost | 3.3/5.0V (Typ.)(VDD) |
| aplikacija | IA |
