| PartNumber | QD17EL07 Rev.09 |
| Znamka | QDI |
| Velikost | 17.0 |
| Aplikacija | DMPC |
| Resolucija | 1280×1024 |
| Sestava | LCM |
| Svetlost | 260 |
| CR | 500:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | QDI |
| panelni model | QD17EL07 Rev.09 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 17.0 inch |
| resolucija | 1280(RGB)×1024 , SXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 337.92×270.336 mm |
| oris | 358.5×296.5 mm |
| površino | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| svetlost | 260 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 16.2M (6-bit + FRC) |
| odzivni čas | 2/6 (Typ.)(Tr/Td) |
| vidni kot | 70/70/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 pcsCCFLWithout Driver |
| signalni vmesnik | LVDS (2 ch, 8-bit), 30 pins |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
| B170PW03 V0 | AUO | 17.0 | 1440×900 |
| B170PW03 V3 | AUO | 17.0 | 1440×900 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| LB170E01-SL01 | LG Display | 17.0 | 1280×1024 |
| LC170WXN-SAA1 | LG Display | 17.0 | 1366×768 |
| LQ170M1LA12 | SHARP | 17.0 | 1920×1200 |
| LTN170X2-L03 | Samsung | 17.0 | 1440×900 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| QD17EL07 Rev.09 | QDI | 17.0 | 1280×1024 |
| HR236WU3-301 | BOE | 23.6 | 1920×1080 |
| LM200WD1-TLD1 | LG Display | 20.0 | 1600×900 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM240WU6-SDA1 | LG Display | 24.0 | 1920×1200 |
| LM270WF2-TLA5 | LG Display | 27.0 | 1920×1080 |
| M170EG01 V8 | AUO | 17.0 | 1280×1024 |
| M190E5-L0G | Innolux | 19.0 | 1280×1024 |
| M215HTN01.0 | AUO | 21.5 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
