| PartNumber | QD14XL20 Rev.03 |
| Znamka | QDI |
| Velikost | 14.1 |
| Aplikacija | NBPC |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 185 |
| CR | 300:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | QDI |
| panelni model | QD14XL20 Rev.03 1 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 14.1 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 285.696×214.272 mm |
| oris | 299×240.6×5.5 mm |
| slog oblike | Wedge (PCBA Bent, Depth ≥5.2mm) |
| površino | Antiglare, Hard coating (3H), Reflection 5.0% (Max.) |
| svetlost | 185 cd/m² (Typ.) |
| kontrastno razmerje | 300:1 (Min.) |
| barve zaslona | 262K (6-bit), CIE193142% |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| HT141WXB-100 | BOE | 14.1 | 1280×800 |
| LP141WP2-TLA1 | LG Display | 14.1 | 1440×900 |
| LP141WP2-TPA1 | LG Display | 14.1 | 1440×900 |
| LTN141AT08-304 | Samsung | 14.1 | 1280×800 |
| LTN141AT09-201 | Samsung | 14.1 | 1280×800 |
| LTN141W1-L09-1 | Samsung | 14.1 | 1280×800 |
| N141I3-L05 | Innolux | 14.1 | 1280×800 |
| QD14XL20 Rev.03 | QDI | 14.1 | 1024×768 |
| CLAA154WA05A | CPT | 15.4 | 1280×800 |
| HSD110PHW2-A00 | HannStar | 11.0 | 1366×768 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LT121EE16000 | TOSHIBA | 12.1 | 1280×800 |
| LTD111EV8X | TOSHIBA | 11.1 | 1366×768 |
| LTD121EQ3B | TOSHIBA | 12.1 | 1280×800 |
| LTD121EXFV | TOSHIBA | 12.1 | 1280×768 |
| LTM09C362F | TOSHIBA | 8.9 | 1024×600 |
| LTN154X3-L0D-G | Samsung | 15.4 | 1280×800 |
