| PartNumber | PA064XS2 |
| Znamka | E Ink |
| Velikost | 6.4 |
| Aplikacija | CNS |
| Resolucija | 320×234 |
| Sestava | LCM |
| Svetlost | |
| CR | 350:1 |
| Barve | Full color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Analog |
| znamka plošče | PVI |
| panelni model | PA064XS2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 6.4 inch |
| resolucija | 320(RGB)×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 129.6×97.3 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 350:1 (Typ.) |
| barve zaslona | Full color |
| odzivni čas | 15/25 (Typ.)(Tr/Td) |
| vidni kot | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | TFT Specific Analog RGB, 30 pins |
| vhodna napetost | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| aplikacija | CNS |
