| PartNumber | CLAA088WA01XN |
| Znamka | CPT |
| Velikost | 8.8 |
| Aplikacija | CNS |
| Resolucija | 1280×480 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | CPT |
| panelni model | CLAA088WA01XN |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.8 inch |
| resolucija | 1280(RGB)×480 , DVGA |
| način prikaza | HFFS, Normally Black, Transmissive |
| aktivno območje | 209.28×78.48 mm |
| oris | 229.6×97.3×6.3 mm |
| površino | Antiglare (Haze 25%) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S14PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit), 60 pins |
| vhodna napetost | 3.3/13.0/20/-6.0V (Typ.)(DVDD/AVDD/IGH/IGL) |
| aplikacija | CNS |
