| PartNumber | LA070WV4-SD01 |
| Znamka | LG Display |
| Velikost | 7.0 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 470 |
| CR | 900:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | LG Display |
| panelni model | LA070WV4-SD01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 170×109.6 mm |
| površino | Antiglare (Haze 11%) |
| svetlost | 470 cd/m² (Typ.) |
| kontrastno razmerje | 900:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193165% |
| odzivni čas | 15/10 (Typ.)(Tr/Td) |
| vidni kot | 70/70/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 7S2PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | CNS |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LA070WV1-TH01 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD03 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| C043GW01 V0 | AUO | 4.3 | 400×234 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| C070VW04 V7 | AUO | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| LS080HT111 | Innolux | 8.0 | 800×600 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| PM070WT2 | E Ink | 7.0 | 800×480 |
