| PartNumber | NL192120AC25-02 |
| Znamka | NLT |
| Velikost | 22.5 |
| Aplikacija | DMPC |
| Resolucija | 1920×1200 |
| Sestava | LCM |
| Svetlost | 420 |
| CR | 800:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | CCFL |
| Vmesnik | LVDS |
| znamka plošče | NEC |
| panelni model | NL192120AC25-02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 22.5 inch |
| resolucija | 1920(RGB)×1200 , WUXGA |
| način prikaza | UA-SFT, Normally Black, Transmissive |
| aktivno območje | 483.84×302.4 mm |
| oris | 542×362 mm |
| površino | Antiglare, Hard coating (2H) |
| svetlost | 420 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 1.07B (10-bit), Adobe97% |
| odzivni čas | 6/6 (Typ.)(Tr/Td) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 120Hz |
| tip svetilke | 12 pcsCCFLEmbedded (Inverter) |
| signalni vmesnik | LVDS (4 ch, 10-bit), 104 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | DMPC |
| NL192120AC25-02 | NLT | 22.5 | 1920×1200 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LM215WF8-TLA1 | LG Display | 21.5 | 1920×1080 |
| LM220WE3-TLA1 | LG Display | 22.0 | 1680×1050 |
| LM240WU7-SLA1 | LG Display | 24.0 | 1920×1200 |
| LM300W01-STA1 | LG Display | 30.0 | 2560×1600 |
| LTM240CT01 | Samsung | 24.0 | 1920×1200 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
| M156B1-L02 | Innolux | 15.6 | 1366×768 |
| M230HGE-L20 | Innolux | 23.0 | 1920×1080 |
