| PartNumber | NL12876BC15-01 |
| Znamka | NLT |
| Velikost | 8.9 |
| Aplikacija | NBPC |
| Resolucija | 1280×768 |
| Sestava | LCM |
| Svetlost | 280 |
| CR | 500:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | NEC |
| panelni model | NL12876BC15-01 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.9 inch |
| resolucija | 1280(RGB)×768 , WXGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 193.92×116.352 mm |
| oris | 209.2×130.3×7.7 mm |
| površino | Clear, Hard coating (3H) |
| svetlost | 280 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193156% |
| odzivni čas | 6/2 (Typ.)(Tr/Td) |
| vidni kot | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 11S3PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | NBPC |
