| PartNumber | NDS0708001280-31 |
| Znamka | SEBO |
| Velikost | 7.0 |
| Aplikacija | PAD |
| Resolucija | 800×1280 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SEBO |
| panelni model | NDS0708001280-31 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×1280 , WXGA |
| način prikaza | Normally Black, Transmissive |
| aktivno območje | 94.2×150.72 mm |
| oris | 104.32×161.67×4.19 mm |
| površino | |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 16.7M (8-bit) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 5S5PWLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 8-bit), 31 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
