| PartNumber | N125HCE-G61 |
| Znamka | Innolux |
| Velikost | 12.5 |
| Aplikacija | Laptop Pad & Tab |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | Innolux |
| panelni model | N125HCE-G61 (CMN1244) |
| velikost plošče | 12.5" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1920(RGB)×1080, FHD, 176PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 276.48(W)×155.52(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 290.5(W)×170.7(H) ×4.85(D) mm |
| površino | Glare (Haze 0%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način prikaza | AAS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 14/11 (Typ.)(Tr/Td) |
| barve zaslona | 262K 50% NTSC |
| tip svetilke | WLED , 15K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| slog oblike | Slim (PCBA Bent, T≤3.0mm) |
| aplikacija | Laptop Pad & Tablet |
| signalni vmesnik | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HB125WX1-200 | BOE | 12.5 | 1366×768 |
| LP125WF2-SPB1 | LG Display | 12.5 | 1920×1080 |
| LP125WH2-SLB1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPM2 | LG Display | 12.5 | 1366×768 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| LP125WH2-TLD1 | LG Display | 12.5 | 1366×768 |
| LTN125AT02-301 | Samsung | 12.5 | 1366×768 |
| M125NWN1 R0 | IVO | 12.5 | 1366×768 |
| N125HCE-GN1 | Innolux | 12.5 | 1920×1080 |
