| PartNumber | N080XCG-L21 |
| Znamka | Innolux |
| Velikost | 8.0 |
| Aplikacija | |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | CHIMEI INNOLUX |
| panelni model | N080XCG-L21 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 8.0 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 162.048×121.536 mm |
| oris | 183×141×2.9 mm |
| površino | Glare (Haze 0%), Hard coating (3H) |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| odzivni čas | 13/12 (Typ.)(Tr/Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 40 pins |
| vhodna napetost | 3.3/10.6V (Typ.)(VDD/AVDD) |
