| PartNumber | MCT-G320240DTCW-151N |
| Znamka | TRULY |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | CSTN-LCD , LCM |
| Svetlost | |
| CR | 45:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel |
| znamka | TRULY |
| velikost diagonale | 5.7 inch |
| slikovnih pik | 320(RGB)×240 [QVGA] 70PPI |
| aktivno območje | 115.18(H)×86.38(V) mm |
| območje okvirja | 119.18(H)×90.38(V) mm |
| svetilnost | 220 cd/m² (Typ.) |
| smer pogleda | - |
| vidni kot | 50/50/55/40 (Typ.)(CR≥10) |
| podpira barvo | Color |
| utež | - |
| hitrost sličic | - |
| tip vmesnika | Parallel Data (1ch, 8-bit) , 16 pins Connector |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -10 ~ 60 °C |
| model | MCT-G320240DTCW-151N |
| vrsta | CSTN-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 158.5(H)×109(V) ×9.2(D) mm |
| zdravljenje | - |
| kontrastno razmerje | 45:1 (Typ.) (TM) |
| odzivni čas | 215/110 (Typ.)(Tr/Td) |
| način delovanja | STN, Normally Black, Transmissive |
| Izvor svetlobe | CCFL [1 pcs] , 15K hours , W/O Driver |
| namenjen za | Industrial |
| plošča na dotik | Without |
| AG-320240A4FIQW-K9H-S(N)(R) | AMPIRE | 5.7 | 320×240 |
| DLC0570BDG-T-2 | Other | 5.7 | 640×480 |
| DLC0570FDG | Other | 5.7 | 320×240 |
| EL320.240.36 HB NE CC | PLANAR | 5.7 | 320×240 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| PD057VU4 | E Ink | 5.7 | 320×240 |
| SP14Q001-X | KOE | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
| TX14D22VM1BAA | KOE | 5.7 | 320×240 |
