| PartNumber | M150X3-T05 |
| Znamka | Innolux |
| Velikost | 15.0 |
| Aplikacija | DMPC |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 300:1 |
| Barve | 262K |
| Osvetlitev ozadja | CCFL |
| Vmesnik | TTL |
| znamka plošče | CMO |
| panelni model | M150X3-T05 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 15.0 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 304.128×228.096 mm |
| oris | 331.6×254.76×13.5 mm |
| površino | |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 300:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 7/23 (Typ.)(Tr/Td) |
| vidni kot | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 pcsCCFLWithout Driver |
| signalni vmesnik | TTL (2 ch, 6-bit), 60 pins |
| vhodna napetost | 3.3V (Typ.)(VDD) |
| aplikacija | DMPC |
| FLC38XGC6V-06 | Fujitsu | 15.0 | 1024×768 |
| G150XTN03.1 | AUO | 15.0 | 1024×768 |
| LB150X03-TL03 | LG Display | 15.0 | 1024×768 |
| LQ150X1LW71N | SHARP | 15.0 | 1024×768 |
| M150X3-T05 | Innolux | 15.0 | 1024×768 |
| M150XN07 V1 | AUO | 15.0 | 1024×768 |
| M150XN07 V2 | AUO | 15.0 | 1024×768 |
| M150XN07 V9 | AUO | 15.0 | 1024×768 |
| M150XS03 V1 | AUO | 15.0 | 1024×768 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| AA150XA03B | Mitsubishi | 15.0 | 1024×768 |
| HM215WU1-500 | BOE | 21.5 | 1920×1080 |
| LM190E0A-SLA1 | LG Display | 19.0 | 1280×1024 |
| LM230WF5-TLD1 | LG Display | 23.0 | 1920×1080 |
| LM240WU8-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM300WQ6-SLA1 | LG Display | 30.0 | 2560×1600 |
| M150XN07 V9 | AUO | 15.0 | 1024×768 |
| M185XW01 V4 | AUO | 18.5 | 1366×768 |
| M215HJJ-P02 | Innolux | 21.5 | 1920×1080 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
