| PartNumber | LS024Q8UC02 |
| Znamka | SHARP |
| Velikost | 2.4 |
| Aplikacija | MPH |
| Resolucija | 240×320 |
| Sestava | CELL |
| Svetlost | 0 |
| CR | 90:1 |
| Barve | 65K |
| Osvetlitev ozadja | No B/L |
| Vmesnik | CPU |
| znamka plošče | SHARP |
| panelni model | LS024Q8UC02 |
| vrsta plošče | CG-Silicon , CELL |
| velikost plošče | 2.4 inch |
| resolucija | 240(RGB)×320 , QVGA |
| način prikaza | TN, Normally White, Transflective |
| aktivno območje | 36.72×48.96 mm |
| oris | 41.7×83.65×1.75 mm |
| površino | Hard coating |
| transmisivnost | 8.2% (Typ.)(with Polarizer) |
| kontrastno razmerje | 90:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| barve zaslona | 65K , CIE193159% |
| odzivni čas | 60 (Typ.)(Tr+Td) |
| vidni kot | 35/35/40/30 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| signalni vmesnik | CPU, 36 pins |
| vhodna napetost | 2.85V (Typ.) |
| aplikacija | MPH |
