| PartNumber | RX024A-03 |
| Znamka | ROGIN |
| Velikost | 2.4 |
| Aplikacija | IA |
| Resolucija | 480×234 |
| Sestava | LCM |
| Svetlost | 200 |
| CR | 400:1 |
| Barve | |
| Osvetlitev ozadja | WLED |
| Vmesnik | Serial RGB |
| znamka plošče | ROGIN |
| panelni model | RX024A-03 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 2.4 inch |
| resolucija | 480×234 |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 48×35.685 mm |
| oris | 54.8×47.15×2.9 mm |
| površino | |
| svetlost | 200 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | , CIE193145% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | 2 pcsWLEDWithout Driver |
| signalni vmesnik | Serial RGB (8-bit) + SPI, 40 pins |
| vhodna napetost | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| aplikacija | IA |
