| PartNumber | LQ156Z1JW03B |
| Znamka | Sharp |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 3200×1800 |
| Sestava | LCM , Oxide TFT-LC |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| proizvajalec | Sharp |
| velikost zaslona | 15.6 inch |
| število slikovnih pik | 3200(RGB)×1800 (Quad-HD+) 235PPI |
| aktivna površina (mm) | 345.6 × 194.4 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 300 cd/m² (Typ.) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 100% sRGB |
| obrisna oblika | Slim (PCBA Flat, T≤3.2mm) |
| hitrost osveževanja | 60Hz |
| vrsto signala | eDP (4 Lanes) , eDP1.3 , HBR2 (5.4G/lane) , 40 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| ime modela | LQ156Z1JW03B (SHP141C) |
| vrsto zaslona | LCM , Oxide TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 367.98 × 218.21 × 2.85 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| način dela | New Mode, Normally Black, Transmissive |
| osvetlitev ozadja | WLED , With LED Driver |
| uporablja za | Laptop |
| zaslon na dotik | Without |
