| PartNumber | LQ092B5DW02 |
| Znamka | SHARP |
| Velikost | 9.2 |
| Aplikacija | IA |
| Resolucija | 960×160 |
| Sestava | LCM |
| Svetlost | 1050 |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | SHARP |
| panelni model | LQ092B5DW02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 9.2 inch |
| resolucija | 960(RGB)×160 |
| način prikaza | ASV, Normally Black, Transmissive |
| aktivno območje | 230.4×38.4 mm |
| oris | 242×52.83×10.8 mm |
| površino | Antiglare |
| svetlost | 1050 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 8/6 (Typ.)(Tr/Td) |
| vidni kot | |
| pogostost | 60Hz |
| tip svetilke | 6S4PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 50 pins |
| vhodna napetost | 3.3/13.4/25.0/-8.0V (Typ.)(VSHD/VSHA/VGH/VGL) |
| aplikacija | IA |
