| PartNumber | LQ050W1LA0A |
| Znamka | SHARP |
| Velikost | 5.0 |
| Aplikacija | UMPC |
| Resolucija | 1024×600 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 450:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SHARP |
| panelni model | LQ050W1LA0A |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 1024(RGB)×600 , WSVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 109.1×63.9 mm |
| oris | 119×76.3×5.6 mm |
| površino | Antiglare, Hard coating (2H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 450:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 6-bit), 30 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | UMPC |
