| PartNumber | LQ050A5AG03 |
| Znamka | Sharp |
| Velikost | 5.0 |
| Aplikacija | Automotive Display |
| Resolucija | 320×234 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 60:1 |
| Barve | Full |
| Osvetlitev ozadja | 1 |
| Vmesnik | Analog |
| proizvajalec | Sharp |
| ime modela | LQ050A5AG03 |
| velikost zaslona | 5.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 320(RGB)×234 79PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 102.124 × 74.763 (H×V) |
| obris (mm) | 126.8 × 89.9 × 16.5 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antireflection |
| svetilnost | 320 cd/m² (Typ.) |
| kontrastno razmerje | 60 : 1 (Typ.) (TM) |
| vidni kot | 65/65/40/65 (Typ.)(CR≥5) |
| odgovor | 30/50 (Typ.)(Tr/Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | Full color |
| osvetlitev ozadja | 1 pcs CCFL , 10K hours , No Driver |
| masa | 180g (Max.) |
| uporablja za | Automotive Display |
| hitrost osveževanja | - |
| zaslon na dotik | Without |
| vrsto signala | Analog RGB , Connector 22 pins |
| napajanje z napetostjo | 8.0/-5.0V (Typ.)(VSH/VSL) |
| maks. ocene | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
