| PartNumber | LP101WH4-SLP2 |
| Znamka | LG Display |
| Velikost | 10.1 |
| Aplikacija | PAD |
| Resolucija | 1366×768 |
| Sestava | LCM |
| Svetlost | 380 |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | LG Display |
| panelni model | LP101WH4-SLP2 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.1 inch |
| resolucija | 1366(RGB)×768 , WXGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 222.52×125.11 mm |
| oris | 232.8×138.15×4.35 mm |
| površino | Antiglare, Hard coating (3H), Antireflection |
| svetlost | 380 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193150% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 8-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
