| PartNumber | KCB6448BSTT-X4 |
| Znamka | Kyocera |
| Velikost | 10.4 |
| Aplikacija | IA |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | |
| CR | 20:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | Kyocera |
| panelni model | KCB6448BSTT-X4 |
| vrsta plošče | CSTN-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 640(RGB)×480 , VGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno območje | 211.2×158.4 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 20:1 (Typ.) |
| barve zaslona | Color , CIE193140% |
| odzivni čas | 160/80 (Typ.)(Tr/Td) |
| vidni kot | |
| pogostost | 75Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (2ch, 8-bit) |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | IA |
