| PartNumber | H220VA01 |
| Znamka | AUO |
| Velikost | 2.2 |
| Aplikacija | Mobile Phone |
| Resolucija | 240×320 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 75:19:1 |
| Barve | 262K |
| Osvetlitev ozadja | 4S1P |
| Vmesnik | Parallel |
| proizvajalec | AUO |
| velikost zaslona | 2.2 inch |
| število slikovnih pik | 240(RGB)×320 (QVGA) 180PPI |
| aktivna površina (mm) | 33.84 × 45.12 (H×V) |
| površina okvirja (mm) | 35.4 × 46.92 (H×V) |
| svetilnost | 100 cd/m² (Typ.) |
| vidni kot | 47/28/30/80 (Typ.)(CR≥10) |
| dober pogled na | 6 o'clock |
| barvna globina | 262K 42% NTSC |
| masa | - |
| hitrost osveževanja | - |
| vrsto signala | Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC |
| napajanje z napetostjo | 2.8V (Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| ime modela | H220VA01 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 40.6 × 56.66 × 3.11 (H×V×D) |
| zdravljenje | - |
| kontrastno razmerje | 75 : 1 (Typ.) (TM) 9:1 (Typ.) (RF) |
| odgovor | 29 (Typ.)(Tr+Td) ms |
| način dela | TN, Normally White, Transflective |
| osvetlitev ozadja | 4S1P WLED , No Driver |
| uporablja za | Mobile Phone |
| zaslon na dotik | Without |
