| PartNumber | BTL507212-W749L |
| Znamka | BOE |
| Velikost | 5.0 |
| Aplikacija | MPH |
| Resolucija | 720×1280 |
| Sestava | LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | BOE |
| panelni model | BTL507212-W749L |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 5.0 inch |
| resolucija | 720(RGB)×1280 , WXGA |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno območje | 62.1×110.4 mm |
| površino | |
| svetlost | |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193170% |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 27 pins |
| vhodna napetost | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| aplikacija | MPH |
