| PartNumber | LS027B7DH01 |
| Znamka | SHARP |
| Velikost | 2.7 |
| Aplikacija | HHP |
| Resolucija | 400×240 |
| Sestava | LCM |
| Svetlost | |
| CR | |
| Barve | Monochrome |
| Osvetlitev ozadja | No B/L |
| Vmesnik | SPI |
| znamka plošče | SHARP |
| panelni model | LS027B7DH01 |
| vrsta plošče | CG-Silicon , LCM |
| velikost plošče | 2.7 inch |
| resolucija | 400×240 , WQVGA |
| način prikaza | Transflective |
| aktivno območje | 58.8×35.28 mm |
| oris | 62.8×42.82 mm |
| površino | Hard coating (3H) |
| svetlost | |
| kontrastno razmerje | 14:1 (Typ.)(Reflective) |
| barve zaslona | Monochrome (1-bit) |
| odzivni čas | 10/20 (Typ.)(Tr/Td) |
| vidni kot | 55/55/60/60 (Min.)(CR≥2)(L/R/U/D) |
| tip svetilke | No B/L |
| signalni vmesnik | SPI, 10 pins |
| vhodna napetost | 5.0/5.0V (Typ.)(VDD/VDDA) |
| aplikacija | HHP |
