| PartNumber | G649DX5R010 |
| Znamka | SII |
| Velikost | 8.9 |
| Aplikacija | Industrial |
| Resolucija | 640×200 |
| Sestava | FSTN-LCD, LCM |
| Svetlost | |
| CR | 8:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel |
| znamka | SII |
| model | G649DX5R010 |
| velikost diagonale | 8.9 inch |
| vrsta | FSTN-LCD, LCM |
| slikovnih pik | 640×200 75PPI |
| konfiguracijo | Rectangle |
| aktivno območje | 211.17(H)×79.17(V) mm |
| obris dim. | 260(H)×110.7(V) ×15(D) mm |
| območje okvirja | 216.0(H)×83.2(V) mm |
| zdravljenje | - |
| svetilnost | 100 cd/m² (Typ.) |
| kontrastno razmerje | 8:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 250/150 (Typ.)(Tr/Td) |
| vidni kot | - |
| način delovanja | STN, Black/White (Negative), Transmissive |
| podpira barvo | Monochrome |
| Izvor svetlobe | CCFL [1 pcs] , 12K hours , W/O Driver |
| utež | 420g (Typ.) |
| namenjen za | Industrial |
| hitrost sličic | 70Hz |
| plošča na dotik | Without |
| tip vmesnika | Parallel Data (1ch, 4-bit) PIN |
| napajanje | 5.0/-24.0V (Typ.)(VDD/VLC) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
