| PartNumber | G270QAN02.0 |
| Znamka | AUO |
| Velikost | 27.0 |
| Aplikacija | Industrial |
| Resolucija | 2560×1440 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 4 |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| ime modela | G270QAN02.0 |
| velikost zaslona | 27.0 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 2560(RGB)×1440 (Quad-HD) 108PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 596.74 × 335.66 (H×V) |
| obris (mm) | 606.44 × 355.56 × 15.03 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 8/8 (Typ.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M 99% sRGB |
| osvetlitev ozadja | 4 strings WLED , 30K hours , No Driver |
| masa | 3.50Kgs (Typ.) |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (4 ch, 8-bit) , 70 pins Connector |
| napajanje z napetostjo | 5.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C |
