| PartNumber | LTM270DL04 |
| Znamka | Samsung |
| Velikost | 27.0 |
| Aplikacija | DMPC |
| Resolucija | 2560×1440 |
| Sestava | LCM |
| Svetlost | 300 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | SAMSUNG |
| panelni model | LTM270DL04 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 27.0 inch |
| resolucija | 2560(RGB)×1440 , Quad-HD |
| način prikaza | PLS, Normally Black, Transmissive |
| aktivno območje | 596.736×335.664 mm |
| površino | Antiglare (Haze 42%), Hard coating (3H) |
| svetlost | 300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 12 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | LVDS (4 ch, 8-bit) |
| vhodna napetost | 5.0V (Typ.) |
| aplikacija | DMPC |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| LM270WR2-SPA1 | LG Display | 27.0 | 3840×2160 |
| LTM270DL02 | Samsung | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270DL06 | Samsung | 27.0 | 2560×1440 |
| LTM270HL02 | Samsung | 27.0 | 1920×1080 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| LM190E08-TLG4 | LG Display | 19.0 | 1280×1024 |
| LTM150XO-L01 | Samsung | 15.0 | 1024×768 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| M200RW01 V6 | AUO | 20.0 | 1600×900 |
| M240J1-L03 | Innolux | 24.0 | 1920×1200 |
| M270HTN01.0 | AUO | 27.0 | 1920×1080 |
| T215HVN01.0 | AUO | 21.5 | 1920×1080 |
