| PartNumber | M270DTN01.0 |
| Znamka | AUO |
| Velikost | 27.0 |
| Aplikacija | DMPC |
| Resolucija | 2560×1440 |
| Sestava | LCM |
| Svetlost | 350 |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | AUO |
| panelni model | M270DTN01.0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 27.0 inch |
| resolucija | 2560(RGB)×1440 , Quad-HD |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 596.736×335.664 mm |
| oris | 613.6×356.85×10.9 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 3.5/1.5 (Typ.)(Tr/Td) |
| vidni kot | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 144Hz |
| tip svetilke | 18S4PWLEDWithout Driver |
| signalni vmesnik | LVDS (8 ch, 8-bit), 130 pins |
| vhodna napetost | 12.0V (Typ.) |
| aplikacija | DMPC |
