| PartNumber | G121X1-L04 |
| Znamka | Innolux |
| Velikost | 12.1 |
| Aplikacija | CNS |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 700:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | CMO |
| panelni model | G121X1-L04 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 12.1 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 245.76×184.32 mm |
| oris | 260.5×204×7.7 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 262K/16.2M (6-bit / 6-bit + FRC), CIE193163% |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| vidni kot | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDEmbedded (LED Driver) |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 20 pins |
| vhodna napetost | 3.3/5.0V (Typ.) |
| aplikacija | CNS |
