| PartNumber | ES050YMM-A00 |
| Znamka | BOE |
| Velikost | 5.0 |
| Aplikacija | Round Display Instru |
| Resolucija | 1080×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1300:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | BOE |
| ime modela | ES050YMM-A00 |
| velikost zaslona | 5.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1080(RGB)×1080 215PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 127.008 × 127.008 (H×V) |
| obris (mm) | 143 × 140 × 4.45 (H×V×D) |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 1300 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 40 (Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | ADS, Normally Black, Transmissive |
| barvna globina | 16.7M 80% NTSC |
| osvetlitev ozadja | WLED , No Driver |
| masa | - |
| uporablja za | Round Display Instruments & Meters Home Appliance |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | PCAP |
| Storage Temp.: -30 ~ 75 °C Operating Temp.: -20 ~ 60 °C |
