| PartNumber | AV128HDM-NW0 |
| Znamka | BOE |
| Velikost | 12.8 |
| Aplikacija | CNS |
| Resolucija | 1280×720 |
| Sestava | LCM |
| Svetlost | 500 |
| CR | 900:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | BOE |
| panelni model | AV128HDM-NW0 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 12.8 inch |
| resolucija | 1280(RGB)×720 , WXGA |
| način prikaza | ADS, Normally Black, Transmissive |
| aktivno območje | 283.2×159.3 mm |
| oris | 300.8×179.5×8 mm |
| površino | |
| svetlost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 900:1 (Typ.) |
| barve zaslona | 16.7M (8-bit), CIE193172% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4S10PWLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 8-bit), 50 pins |
| vhodna napetost | 3.3/11.5/22/-9V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikacija | CNS |
