| PartNumber | L5F30818P04 |
| Znamka | SONY |
| Velikost | 6.5 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 550 |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | SONY |
| panelni model | L5F30818P04 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 6.5 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | Normally Black, Transmissive |
| aktivno območje | 144×78.24 mm |
| oris | 159.9×93.4 mm |
| površino | |
| svetlost | 550 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 4 stringsWLEDWithout Driver |
| signalni vmesnik | CMOS (1 ch, 6-bit) + SPI, 50 pins |
| vhodna napetost | 3.3V (Typ.) |
| rohs: | |
| aplikacija | CNS |
