| PartNumber | AT065TN14 |
| Znamka | Innolux |
| Velikost | 6.5 |
| Aplikacija | CNS |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | INNOLUX |
| panelni model | AT065TN14 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 6.5 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 143.4×76.7 mm |
| oris | 155.2×89.4×5.7 mm |
| površino | Antiglare |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 262K/16.7M (6-bit / 6-bit + Dithering), CIE193150% |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 3S8PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 8-bit), 50 pins |
| vhodna napetost | 3.3/10.4/16.0/-7.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| aplikacija | CNS |
| AA065VE01 | Mitsubishi | 6.5 | 640×480 |
| AT062TN12 | Innolux | 6.2 | |
| AT065TN14 | Innolux | 6.5 | 800×480 |
| C065GW03 V0 | AUO | 6.5 | 400×240 |
| G065VN01 V1 | AUO | 6.5 | 640×480 |
| KHB065HV1BD-M10 | Kyocera | 6.5 | 640×240 |
| L5F30947T00 | Epson | 6.5 | 800×480 |
| LQ065T5DG30 | SHARP | 6.5 | 400×240 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| LTA065B626A | TOSHIBA | 6.5 | 400×234 |
| C035QVN01.0 | AUO | 3.5 | 240×320 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| FG0700K5DSSWBG01 | Data Image | 7.0 | 800×480 |
| LA070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LAJ080W001A | TPO | 8.0 | 800×480 |
| LB080WV3-A3 | LG Display | 8.0 | 800×480 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| LQ7BW566AH | SHARP | 7.0 | 480×234 |
| T-51965GD088ZU-MFW-AEN | Kyocera | 8.8 | 640×240 |
